| ■TCP2ポンプ配管フランジ取付ネジChangeのご案内■ |
| 2009年8月18日 |
| 1.主旨 |
| TCP2シリーズポンプのカバーのIN-side pipe flange取付ネジの安全化のためネジ深さのChangeを致します。 |
| 2. Description of change |
| TCP2 |
|
| The specificztions zre zs shown in the tzble below zs z result of the chznge of the IN pipe flznge mounting screws |
| Description of chznge | Current | Change | Remarks |
| Mounting bolt depth | Screw: M10, pitch 1.5 Depth: 20 |
Screw: M10, pitch 1.5 Depth: 16 |
― |
| IN-side pipe flange | FTCP-06PT | FHPP-06PT | 配管フランジ、Mounting boltは ポンプには付属していません (別売) |
| FTCP-06WE | FHPP-06WE | ||
| Mounting bolt | TA-B2-10×40 | TA-B2-10×35 |
| 3. Target models | ||
| 1) Internal gear pump | ||
| TCP2-**-M*1-A | ||
| TCP2-**-M*1-A-*** |
| 2) Internal gear pump (double pump) | ||
| TCP2 side of TCP24-**・*-M*1-A-*** | ||
| TCP2 side of TCP25-**・*-M*1-A-*** |
| 3) Internal gear pump (two-stage pump) | ||
| TCP2T-**-H*1-A |
| 4. Switching timing |
| The switching of products will begin from deliveries in September 2009. |
